3COM_OS_SW8800_V3.01.32rc13_Release_Notes

3COM OS SW8800 V3.01.32rc13 Release Notes
April 25, 2013 Page 44 of 56
7. Modify bootrom password
0. Reboot
At this time, you can download program files through the Ethernet port or the console port.
A. Download BootROM Program through Ethernet interface
Choose <5> in the main menu of MPU BootROM and enter the Ethernet submenu:
ETHERNET SUBMENU
1. Download file to SDRAM through ethernet interface and boot
2. Download file to Flash through ethernet interface
3. Download file to CF card through ethernet interface
4. Modify ethernet interface boot parameter
0. Return to main menu
First choose <4> to change the parameters of the Ethernet interface:
Enter your choice(0-4): 4
Note: Two protocols for download, tftp & ftp.
You can modify the flags following the menu.
tftp--0x80, ftp--0x0.
'.' = clear field; '-' = go to previous field; ^D = quit
boot device : fei0
processor number : 0
host name : 8800
file name : mpu.APP LSBSRP1N01303.APP
inet on ethernet (e) : 10.110.139.17 192.168.0.90
inet on backplane (b):
host inet (h) : 10.110.139.20 192.168.0.91
gateway inet (g) :
user (u) : 8800
ftp password (pw) (blank = use rsh): 123
flags (f) : 0x0
target name (tn) :
startup script (s) :
other (o) :
Write flash...done!
Run FTP Server on the computer, and configure the same user name, password and file directory as
above. Choose <2> to download the program file to Flash memory:
ETHERNET SUBMENU
