3COM_OS_SW8800_V3.01.32rc13_Release_Notes

3COM OS SW8800 V3.01.32rc13 Release Notes
April 25, 2013 Page 45 of 56
1. Download file to SDRAM through ethernet interface and boot
2. Download file to Flash through ethernet interface
3. Download file to CF card through ethernet interface
4. Modify ethernet interface boot parameter
0. Return to main menu
Enter your choice(0-4): 2
boot device : fei
unit number : 0
processor number : 0
host name : 8800
file name : LSBSRP1N01303.APP
inet on ethernet (e) : 192.168.0.90
host inet (h) : 192.168.0.91
user (u) : 8800
ftp password (pw) : 123
flags (f) : 0x0
Prepare for loading....OK
Loading....done
Free flash Space : 15862784 bytes
Writing
Flash...................................................................................
.......................................Done
B. Download BootROM program files through serial port
Choose <4> in the main menu of MPU BootROM and enter the serial port submenu:
SERIAL SUBMENU
1. Download file to SDRAM through serial interface and boot
2. Download file to Flash through serial interface
3. Download file to CF card through serial interface
4. Modify serial interface boot parameter
0. Return to main menu
To set the baud rate of the serial port, choose <4> and enter the following menu to select the
corresponding rate:
Enter your choice(0-4): 4
1: 9600(default)
2: 19200
3: 38400
4: 57600
5: 115200
