3COM OS SW8800 V3.01.32rc13 Release Notes
April 25, 2013 Page 46 of 56
please select an appropriate baudrate:
Enter your choice(1-5): 5
BaudRate is 115200 bps. Please change the terminal's speed to 115200 bps
Return to the serial port submenu after the setting. Choose <2> to download the program file to Flash
memory. Select the program file to be downloaded and XMODEM protocol on HyperTerminal. Then
begin to download the program file:
SERIAL SUBMENU
1. Download file to SDRAM through serial interface and boot
2. Download file to Flash through serial interface
3. Download file to CF card through serial interface
4. Modify serial interface boot parameter
0. Return to main menu
Enter your choice(0-4): 2
Please Select File .
XMODEM downloading ...CC download successfully!
Free flash Space : 15862784 bytes
Writing
Flash...................................................................................
...........................................Done
Upgrade BootROM
Press Ctrl+U in the main menu of MPU BootROM. Choose and confirm the number of the file to be
upgraded. Then system starts to upgrade the BootROM :
MAIN MENU
1. Boot with default mode
2. Boot from Flash
3. Boot from CF card
4. Enter serial submenu
5. Enter ethernet submenu
6. Modify Flash description area
7. Modify bootrom password
0. Reboot
Enter your choice(0-7):(Ctrl+U)
No. File Size Date Time File Name
=============================================================
1(*). 24149578 2009-11-28 15:34:40 88h03_01_32rc13.app
2. 326680 2007-01-15 11:45:10 LSBSRP1N01303.APP
