H3C S7500 Series Ethernet Switches Command Manual

Command Manual – Infomation Center
H3C S7500 Series Ethernet Switches Chapter 1
Information Center Commands
1-18
Channel Log information Trap information
Debug
information
Channel9 Enable Enable Disable
state: State of information.
state: on or off.
Description
Use the info-center source command to specify the information source in the
information center and the output direction.
Use the undo info-center source command to cancel the configured information
source and output direction.
This command can be used for filtering log, trap or debugging information. For example,
it can control information output from the IP module to a self-defined direction. You can
configure to output information with a severity higher than “warning” to the log host, and
information with a severity higher than “informational” to the log buffer. You can also
configure to output trap information to the log host at the same time.
The info-center source command determines the output direction according to a
channel name or channel number. Each output direction is assigned a default
information channel at present, as shown in the following table.
Table 1-7 Default information channel in each output direction
Output direction Information channel name
Console console
Monitor monitor
Info-center loghost loghost
Log buffer logbuffer
Trap buffer trapbuffer
Snmpagent snmpagent
In addition, each information channel has a default record with a module name of
“default” and a module number of 0xffff0000. However, for different information
channels, the default log, trap and debugging settings in the records may be different
from one another. Use the default configuration record if a module does not have any
explicit configuration record in the channel.
