H3C S7500 Series Ethernet Switches Command Manual

Command Manual – Port Basic Configuration
H3C S7500 Series Ethernet Switches Chapter 1
Port Basic Configuration Commands
1-18
Description
Use the mdi command to set the network types that can be identified by the Ethernet
port.
Use the undo mdi command to restore the default network cable type that can be
identified by the Ethernet port.
By default, the port identifies the network type automatically.
Caution:
The S7500 series switches support the auto mode only. If another mode is specified,
the system prompts “Operation not supported!”.
Examples
# Specify Ethernet 2/0/1 to identify the network cable type automatically.
<H3C> system-view
System View: return to User View with Ctrl+Z.
[H3C] interface Ethernet2/0/1
[H3C-Ethernet2/0/1] mdi auto
1.1.19 multicast-suppression
Syntax
multicast-suppression { ratio | bandwidth { mbps-value | kbps kbps-value } | pps
max-pps }
undo multicast-suppression
View
Ethernet port view
Parameters
ratio: Maximum ratio of received multicast traffic to the total bandwidth on the Ethernet
port. The value ranges from 1 to 100 (in step of 1) and defaults to 100. The smaller the
ratio is, the less multicast traffic is allowed to be received.
mbps-value: Maximum bandwidth (in Mbps) for receiving multicast traffic on an
Ethernet port. The range of the mbps-value argument depends on the port type:
z 1 to 100 for 100 Mbps Ethernet ports;
z 1 to 1,000 for Gigabit Ethernet ports;
