H3C S7500 Series Ethernet Switches Command Manual

Command Manual – MSTP
H3C S7500 Series Ethernet Switches Chapter 1
MSTP Configuration Commands
1-20
Description
Use the stp interface edged-port enable command to configure the specified
Ethernet port(s) as edge ports in system view.
Use the stp interface edged-port disable command to configure the specified
Ethernet port(s) as non-edge ports in system view.
Use the undo stp interface edged-port command to restore the specified Ethernet
port(s) to their default states.
By default, all Ethernet ports of a switch are non-edge ports.
An edge port is a port that is directly connected to a user terminal instead of another
switch or a network segment. Rapid transition is applied to edge ports because, on
these ports, no loops can be incurred by network topology changes. You can enable a
port to transit to the forwarding state rapidly by setting it to an edge port. And you are
recommended to configure the Ethernet ports directly connected to user terminals as
edge ports to enable them to transit to the forwarding state rapidly.
Normally, configuration BPDUs cannot reach an edge port because the port is not
connected to another switch. But when the BPDU guard function is disabled on an
edge port, configuration BPDUs sent deliberately by a malicious user may reach the
port. If an edge port receives a BPDU, it turns to a non-edge port.
Related commands: stp edged-port.
Caution:
Among loop guard function, root guard function and edge port setting, only one can be
valid on a port at one time.
Examples
# Configure Ethernet 2/0/3 as an edge port in system view.
<H3C> system-view
System View: return to User View with Ctrl+Z.
[H3C] stp interface Ethernet 2/0/3 edged-port enable
1.1.19 stp interface loop-protection
Syntax
stp interface interface-list loop-protection
undo stp interface interface-list loop-protection
