H3C S7500 Series Ethernet Switches Command Manual

Command Manual – Routing Protocol
H3C S7500 Series Ethernet Switches Chapter 1 Static Route Configuration Commands
1-3
[H3C-acl-basic-2000] rule permit source 10.1.1.1 0.0.0.255
[H3C-acl-basic-2000] rule deny source any
[H3C-acl-basic-2000] display ip routing-table acl 2000
Routes matched by access-list 2000:
Summary count: 2
Destination/Mask Protocol Pre Cost Nexthop Interface
10.1.1.0/24 DIRECT 0 0 10.1.1.2 Vlan-interface1
10.1.1.2/32 DIRECT 0 0 127.0.0.1 InLoopBack0
Refer to Table 1-1 for the description on the displayed information above.
# Display the detailed information about the active and inactive routes filtered through
basic ACL 2000.
<H3C> display ip routing-table acl 2000 verbose
Routes matched by access-list 2000:
Generate Default: no
+ = Active Route, - = Last Active, # = Both * = Next hop in use
Summary count: 2
**Destination: 10.1.1.0 Mask: 255.255.255.0
Protocol: #DIRECT Preference: 0
*NextHop: 10.1.1.2 Interface: 10.1.1.2(Vlan-interface1)
Vlinkindex: 0
State: <Int ActiveU Retain Unicast>
Age: 7:24 Cost: 0/0 Tag: 0
**Destination: 10.1.1.2 Mask: 255.255.255.255
Protocol: #DIRECT Preference: 0
*NextHop: 127.0.0.1 Interface: 127.0.0.1(InLoopBack0)
Vlinkindex: 0
State: <NoAdvise Int ActiveU Retain Gateway Unicast>
Age: 7:24 Cost: 0/0 Tag: 0
Table 1-2 Description on the fields of the display ip routing-table acl command
Field Description
Destination Destination address
Mask Mask
Protocol Routing protocol that detects this route
Preference Preference of the route
Nexthop Address of the next hop
