H3C S7500 Series Ethernet Switches Command Manual

Command Manual – Routing Protocol
H3C S7500 Series Ethernet Switches Chapter 5 BGP Configuration Commands
5-43
password: Password in character string form with 1 to 16 characters when the simple
keyword is specified in the command or in the event of inputting the password in simple
text mode but the cipher keyword is specified in the command; with 24 characters in
the event of inputting the password in cipher text mode when the cipher keyword is
specified in the command.
Description
Use the peer password command to configure MD5 authentication for BGP during
TCP connection setup.
Use the undo peer password command to cancel the configuration.
By default, BGP does not perform MD5 authentication when TCP connection is set up.
Once MD5 authentication is enabled, both parties involved in the authentication must
be configured with identical authentication modes and passwords. Otherwise, TCP
connection will not be set up because of the failed authentication.
This command is used to configure MD5 authentication for the specific peer only when
the peer group to which the peer belongs is not configured with MD5 authentication.
Otherwise, the peer should be consistent with the peer group.
Examples
# Adopt MD5 authentication on the TCP connection set up between the local router at
10.1.100.1 and the peer router at 10.1.100.2.
<H3C>system-view
System View: return to User View with Ctrl+Z.
[H3C] bgp 100
[H3C-bgp] peer 10.1.100.2 password simple abc
# Perform the similar configuration on the peer.
<H3C>system-view
System View: return to User View with Ctrl+Z.
[H3C] bgp 100
[H3C-bgp] peer 10.1.100.1 password simple abc
5.1.48 peer public-as-only
Syntax
peer group-name public-as-only
undo peer group-name public-as-only
View
BGP view
