H3C S7500 Series Ethernet Switches Command Manual

Command Manual – ACL
H3C S7500 Series Ethernet Switches Chapter 1
ACL Commands
1-22
Table 1-15 Rule information
Parameters Type Function Description
protocol-type
Protocol type
Defines the
protocol type over
Ethernet frames
protocol-type: the
value can be arp,
rarp, ipx, nbx,
pppoe-control, or
pppoe-data.
When the protocol
type is arp, the
rules cannot match
the ARP packets
with the
destination MAC
address as the
MAC address of
Layer 3 interface
or with the
destination MAC
address being all
Fs.
format-type
Link layer
encapsulation type
Defines the link
layer
encapsulation type
in the rule
format-type: the
value can be
802.3/802.2,
802.3, ether_ii, or
snap.
ingress
{ { source-vlan-id |
source-mac-addr
[ source-mac-mas
k ] }* | any }
Source MAC
address
information
Specifies the
source MAC
address range in
the rule
source-mac-addr:
source MAC
address, in the
format of H-H-H
source-mac-mask:
source MAC
address mask, in
the format of
H-H-H, defaults to
ffff-ffff-ffff..
source-vlan-id:
source VLAN ID, in
the range of 1 to
4,094
any indicates all
packets received
from all ports.
