Keyword CoS value in decimal CoS value in binary
network-management 7 111
Description
Use the rule command to define an ACL rule.
Use the undo rule command to delete an ACL rule.
Before you can delete a rule, you must specify the rule ID. If you do not know the rule ID,
you can view it by using the display acl config command.
In the case that you specify the rule ID when defining a rule:
z If the ACL is created with the config keyword specified and the rule identified by
the rule-id argument exists, the settings specified in the rule command overwrite
the counterparts of the existing rule (other settings of the rule remain unchanged).
If the ACL is created with the auto keyword specified, the rules of the ACL cannot
be edited. In this case, the system prompts errors when you execute the rule
command.
z If the rule corresponding to the specified rule ID does not exist, you will create and
define a new rule.
z The content of a modified or created rule must not be identical with the content of
any existing rule; otherwise the rule modification or creation will be failed, and the
system will prompt that the rule already exists.
If you do not specify a rule ID, you will create and define a new rule, and the system will
assign an ID for the rule automatically.
Examples
# Define an ACL to deny the packets with the source MAC address being
000d-88f5-97ed, the destination MAC address being 011-4301-991e, and the 802.1p
priority being 3 to pass.
<H3C> system-view
System View: return to User View with Ctrl+Z.
[H3C] acl number 4000
[H3C-acl-ethernetframe-4000] rule deny cos 3 source 000d-88f5-97ed
ffff-ffff-ffff dest 0011-4301-991e ffff-ffff-ffff
1.1.16 rule (user-defined ACL)
Syntax
rule [ rule-id ] { permit | deny } { rule-string rule-mask offset } &<1-8> [ time-range
time-name ]
undo rule rule-id
