H3C S7500 Series Ethernet Switches Chapter 1
QoS Commands
1-33
 Note:
z Only type-A LPUs support this command.
z In a traffic redirect configuration, the source port and the destination port must be on
the same LPU.
z Only the permit rule can be referenced in this command and applied to hardware.
Examples
# Redirect the packets matching the permit rule in ACL 2000 to GigabitEthernet 2/0/2.
<H3C> system-view
System View: return to User View with Ctrl+Z.
[H3C] interface GigabitEthernet2/0/1
[H3C-GigabitEthernet2/0/1] qos
[H3C-qosb-GigabitEthernet2/0/1] traffic-redirect inbound ip-group 2000
interface gigabitethernet2/0/2
1.1.26 traffic-remark-vlanid
Syntax
traffic-remark-vlanid inbound acl-rule [ system-index ] remark-vlan vlan-id
undo traffic-remark-vlanid inbound acl-rule
 Note:
LPUs that are not A-type support applying the combination of IP ACL rules and link
ACL rules. However, the field defined by the IP ACL rules and link ACL rules cannot be
of more than 32 characters. Otherwise, the combination cannot be applied
successfully.
View
QoS view
Parameters
inbound: Tags the packets received by the port with outer VLAN tags.
acl-rule: Applied ACL rules which can be the combination of various ACL rules. For the
ways of combining ACLs and the description on related parameters, refer to
Table 1-11
and
Table 1-12.
