z The alarm entry is valid forever.
z Entry owner: user1
<H3C> system-view
System View: return to User View with Ctrl+Z.
[H3C]interface Ethernet 2/0/1
[H3C-Ethernet2/0/1] rmon statistics 1
[H3C-Ethernet2/0/1] quit
[H3C] rmon prialarm 2 ((.1.3.6.1.2.1.16.1.1.1.4.1)*100) test 10 changeratio
rising_threshold 50 1 falling_threshold 5 2 entrytype forever owner user1
# Remove the extended alarm entry numbered 2 from the extended alarm table.
[H3C] undo rmon prialarm 2
2.1.11 rmon statistics
Syntax
rmon statistics entry-number [ owner text ]
undo rmon statistics entry-number
View
Ethernet port view
Parameters
entry-number: Statistics entry Index, in the range of 1 to 65535.
owner text: Specifies the owner of the entry, a string pf 1 to 127 characters.
Description
Use the rmon statistics command to add an entry to the statistics table.
Use the undo rmon statistics command to remove an entry from the statistics table.
The RMON statistics management function is used to take statistics of the usage of the
monitored ports and errors occurring to them. The statistics includes the number of the
following items: collisions, CRC error packets, undersized (or oversized) packets,
broadcast and multicast packets, received bytes and received packets.
 Note:
For each port, only one statistics entry can be created, that is to say, if one statistics
entry was already created for a given port, creation of another statistics entry with a
different index number for the same port will not succeed.
