H3C S7502 Ethernet Switch Chapter 7 Software Maintenance
7-2
 Note:
The steps that you should take to load Boot ROM program are the same as those you
take to load host software, except that in a Boot ROM program loading process you
need to press <Ctrl+U> and <Enter> after accessing the Boot ROM menu and will view
a different prompt message. Boot ROM loading steps are described below as an
example.
7.2.1 BOOT Menu
A power-on switch will run the Boot ROM program first and the terminal will display the
following information:
Starting......
RAM Line....OK
System is booting................
******************************************
* *
* H3C S7502 Boot ROM, Version 530 *
* *
******************************************
Copyright(c) 2004-2007 Hangzhou H3C Tech. Co., Ltd.
Creation date : Apr 20 2007, 14:48:52
CPU type : MPC8245
CPU Clock Speed : 300Mhz
BUS Clock Speed : 33Mhz
BOOT_FLASH type : M29W040B
Flash Size : 32MB
Memory Size : 256MB
S7502 main board self testing................................
SDRAM Data lines Selftest.................................OK!
SDRAM Address lines Selftest..............................OK!
SDRAM fast selftest.......................................OK!
Please check LEDs.....................LEDs selftest finished!
CPLD selftest.............................................OK!
The switch Mac address is .....................0000.0309.0004
Press Ctrl+B to enter Boot Menu... 3
Press <Ctrl+B> and the system displays the following message:
Password :
