H3C S7502 Ethernet Switch Chapter 7 Software Maintenance
7-12
III. Loading host software
Follow these steps to download the host software:
Step 1: Select <1> from Boot Menu. The system displays the following information:
1. Set TFTP protocol parameter
2. Set FTP protocol parameter
3. Set XMODEM protocol parameter
0. Return to boot menu
Enter your choice(0-3):3
The subsequent steps are the same as those for loading Boot ROM, except for the
messages displayed.
7.3 Loading Software Remotely or Locally through
Command Lines
If your terminal is connected to the switch through a network, you can load Boot ROM
and host software remotely through command lines.
7.3.1 Loading by FTP
Run the FTP Server on the local PC. Ensure that you have configured the username
and password and set the correct file directory. Assume that the IP address of the PC is
10.10.110.1.
Log in to the switch through Telnet or the console port, to send the host program to the
switch by using FTP.
 Note:
z The S7502 supports dual image booting, that is, usually the switch boots with the
main image (i.e. the primary file), but uses the backup image (i.e. the backup file)
instead when the primary one has any error. Refer to section
7.4 “Booting the
Switch with Dual Images” on page
7-14 for details.
z The S7502 also supports the upgrade by using a combined Boot ROM file, that is,
upgrading the Boot ROM of all cards using a combined Boot ROM file. Refer to
section
7.5 “Loading a Host Software Containing the Boot ROM File” on page 7-16
for details.
Assume that:
z The main boot file is SWITCH002.app.
z The active host software is SWITCH001.app.
z The Boot ROM program is SWITCHbtm.btm.
