H3C S7502 Ethernet Switch Chapter 1 Product Overview
1-25
 Note:
The S7502 provides an independent power over Ethernet (PoE) module and can
remotely provide power to powered devices (PDs), such as IP phone sets, WLAN
access points (APs). There are S7502 PoE chassis and non-PoE chassis. If the PoE
function is required, select an S7502 PoE chassis.
z Console port
The Console port matches RJ45 connector and can be connected to a PC with an
asynchronous serial port cable, for local system debugging, configuration,
maintenance, management, system software loading and so on. It also can be used to
connect to a Modem device for remote debugging, configuration, maintenance,
management and other similar tasks.
Table 1-21 Console port attributes
Item Description
Connector RJ45
Number of connector 1
Electric standard Asynchronous EIA/TIA-232
Baud rate
≤ 115,200 bps, defaults to 9,600 bps
Transmission distance
≤ 15 m (49.2 ft)
Function
z For connection with an ASCII terminal
z Being connected to the serial interface of a local
PC or a remote PC (through a pair of Modems)
running terminal emulation software
z Ethernet interface for management and upgrade (10Base-T/100Base-TX)
The management port matches RJ45 connector and can be used to connect to a PC for
local system debugging, system software loading and other similar tasks, or to a
remote a network management station (NMS) for remote management.
Table 1-22 Attributes of Ethernet interface for management and upgrade
Item Description
Connector RJ45
Number of connector 1
Port rate
z 10 Mbps, half/full duplex
z 100 Mbps, half/full duplex
z MDI-X
