H3C S7502 Ethernet Switch Chapter 1 Product Overview
1-31
1.12 Technical Specifications
Table 1-28 System specifications
Item S7502
Physical dimensions (H × W ×
D)
130.5 x 436 x 400 mm (5.12 x 17.2 x 15.8 in.)
Weight (fully configured) ≤ 25 kg (55 lb )
Number of SRPU slots 1
Number of LPU slots 1
Max number of GE ports 96
Max number of FE ports 48
MTBF (mean time between
failures)
218,000 h
MTTR (mean time to repair) 1 h
AC
Rated voltage: 100 VAC to 240 VAC, 50 Hz to 60
Hz
Input voltage range: 90 VAC to 264 VAC, 50 Hz to
60 Hz
Rated voltage: -48 VDC to -60 VDC
Input voltage range: -36 VDC to -72 VDC
Input voltage
DC
PoE input voltage: -55 V to -46 V, 55.0 A
Operating temperature 0ºC to 45ºC (32ºF to 113ºF)
Relative humidity
(noncondensing)
10% to 90%
