interface-number: Specifies interface number.
Description
Use the display pim interface to display the PIM configuration information
about an interface.
If the interface type and number are not specified, the PIM configuration
information about all the interfaces will be displayed, otherwise the information
about the specified interface will be displayed.
Example
<SW7700>display pim interface
Address Interface Ver/Mode Nbr Cnt Query Intvl DR
8.8.8.8 VLAN-interface1v2/S 1 30 8.8.8.8
192.168.1.1 VLAN-interface2v2/S 0 30 192.168.1.1
display pim neighbor Syntax
display pim neighbor [ interface interface-type interface-number ]
View
All views
Parameter
interface-type interface-number: Interface type and interface number, used
to specify the interface.
Description
Use the display pim neighbor to view the PIM neighbor information.
This command is used for displaying the information about the PIM neighbors
discovered by the Ethernet switch interface. When the parameters are configured,
only the PIM neighbors of the specified interface will be displayed.
Example
<SW7700>display pim neighbor
Neighbor Address Interface Uptime Expires
8.8.8.6 VLAN-interface1 1637 89
Table 20 Output description of the display pim interface command
Field Description
Mode Interface mode (DM or PM)
Query Intvl Hello packet interval
DR Designated router
Nbr Cnt Number of adjacent routers
Table 21 Output description about PIM neighbors
Field Description
Neighbor Address Neighbor address
Interface Interface where the neighbor has been discovered
