Switch 7700 Command reference Guide, v2.0

288 CHAPTER 7: USING QOS/ACL COMMANDS
cos3-map-local-prec: Specifies the mapping value of “COS 3->local-prec”,
which ranges from 0 to 7.
cos4-map-local-prec: Specifies the mapping value of “COS 4->local-prec”,
which ranges from 0 to 7.
cos5-map-local-prec: Specifies the mapping value of “COS 5->local-prec”,
which ranges from 0 to 7.
cos6-map-local-prec: Specifies the mapping value of “COS 6->local-prec”,
which ranges from 0 to 7.
cos7-map-local-prec: Specifies the mapping value of “COS 7->local-prec”,
which ranges from 0 to 7.
Description
■ Use the qos cos-local-precedence-map command to configure “COS
->Local-precedence” map.
■ Use the undo qos cos-local-precedence-map command to restore its default
value.
By default, the system provides the default “COS ->Local-precedence” mapping
relationship.
If needed, you can change “COS->Local-precedence” map using the command.
Example
Configure “COS->Local-precedence” map.
[SW7700]qos cos-local-precedence-map 0 1 2 3 4 5 6 7
After the configuration, the “COS->Local-precedence” map is shown in Table 1-6.
Tab le 22 The default “COS ->Local-precedence” map
COS Local Precedence
2 0
0 1
1 2
3 3
4 4
5 5
6 6
7 7
Tab le 23 “COS->Local-precedence” map
COS Local Precedence
0 0
1 1
2 2
3 3
