SNMP Configuration Commands 469
<SW7700>display snmp-agent group
groupname: public
readview:v1default
writeview: no writeview specified
notifyview: *tv.FFFFFFFF
storage-type: volatile
The following table describes the output fields.
display snmp-agent
mib-view
Syntax
display snmp-agent mib-view [ exclude | include | { viewname mib-view
} ]
View
All views
Parameter
exclude: Display the SNMP mib view excluded.
include: Display the SNMP mib view included.
viewname: Display the SNMP mib view according to the mib view name.
mib-view: Specify the mib view name.
Description
The display snmp-agent mib-view command is used to view the MIB view
configuration information of the Ethernet switch.
Example
Display the information about the currently configured MIB view.
<SW7700>display snmp-agent mib-view
View name:ViewDefault MIB Subtree intertent
storage-type: nonVolatile -included active
View name:ViewDefault MIB Subtree system.0
storage-type: nonVolatile -excluded active
Table 35 Output description of the display snmp-agent group command
Field Description
groupname SNMP Group name of the user
readview Read-only MIB view name corresponding to that group
writeview Writable MIB view corresponding to that group
notifyview The name of the notify MIB view corresponding to that group
storage-type Storage type
