Introduction - Using the Web Management Interface - The Navigation Tree
http://support.3com.com/infodeli/tools/switches/4400/DHA1720-3AAA08/htm/introduction/web/navigationtree.htm[11/15/2010 3:43:21 PM]
Introduction
Using the Web Interface
The Navigation Tree
The Navigation Tree is always displayed on the left side of the browser window. It is a
Windows
®
Explorer-like interface that contains various icons which allow you to manage
your network.
By default, when you open the Web Interface, the
Summary View is selected and the
Navigation Tree is fully collapsed with only the top-level options displayed.
Operations that you can perform to manage your network are grouped into folders within
the Navigation Tree in the
Device View. You can also perform some operations by using
the
device mimic.
Single-click the folders or the nodes (the plus and minus symbols) to expand and
collapse the Navigation Tree.
Every option within the Navigation Tree is selected by single-clicking the left mouse
button.
The following table shows the various Navigation Tree symbols and their associated
behaviour:
Symbol Behavior
Indicates that the next level of the Navigation Tree hierarchy is
currently expanded. Click the symbol to collapse the next level. This
only affects the Navigation Tree — no changes are made to the
Information Area.
Indicates that the next level of the Navigation Tree hierarchy is
currently collapsed. Click the symbol to expand the next level to its
last expanded state. This only affects the Navigation Tree — no
changes are made to the Information Area.
Indicates that the next level of the Navigation Tree hierarchy is
