Restoring Product Operation
where: <slot-ID> is the letter identifier of the switch slot in which the
module is installed. The index number 1 (one) is the context identifier for
the module, not the application running on the module.
If the module has booted into the Service OS, the prompt will include the
characters :SvcOS)# at the end.
Confirm that the CF installation has occurred without any issues by entering
the following command from the Service OS prompt:
:SvcOS)# show version details
The output from this command should shows the correct product information
for SBM product.
From the Service OS prompt, reboot the module into the product OS with the
command:
:SvcOS)# boot ONE-app
At this point, normal operation should be restored.
zl Module Replacement
After installing your original HDD, CF, and PCIe cards into the replacement zl
Module and installing the module into the switch, you should not experience
any need for reconfiguration, or re-licensing of the SBM AllianceONE zl
Module product. Normal operation should be automatically restored.
Notes:
■ If you have configured the module to use DHCP to acquire an IP address,
because the replacement zl Module has a different MAC address than the
faulty module that you have replaced, the new module may have been
assigned a different IP address. This would result in a need to change the
Gateway Properties. Rerun the PSTN Setup Wizard to reconfigure your
replacement module with the new IP address.
If you have configured the module with a static IP address, you do not
need to rerun the PSTN Setup Wizard.
■ Make sure that when you move the PCIe cards from the faulty zl Module
to the replacement zl Module, you install the cards into the same slots that
they were in on the original module. For example, if a 4-Port FXS Analog
Card was in the top slot PCIe slot and a 1-Port T1/E1 Digital Card was in
the bottom slot, then the replacement card(s) must be installed in the
same arrangement. If the cards are replaced in the incorrect slots, then
the gateway will not start and you will be required to rerun the PSTN Setup
Wizard to redo the module configuration.
