Introduction
Hard Disk Drive (HDD)
Depending on the product you have, the HDD is located either on the top board
(referred to as the Upper Deck), attached to four short stand-offs, or on the
bottom side of the bottom board (referred to as the Lower Deck), attached to
a frame. Note that for the HP product, there is a single board. The HDD is on
the bottom side of that board attached to a frame.
Compact Flash (CF)
For all the products, the CF is installed on the bottom of the bottom board,
for the two-board models, or the bottom of the single board.
PCIe Cards
The SBM AllianceONE zl Module product uses PCIe cards installed in two
available slots in the zl Module. These cards are field replaceable units.
zl Module
Replacement zl Modules are delivered without either the HDD or the CF
installed.
Important Install the HDD and CF from your current zl Module into the replacement
module. For the SBM AllianceONE zl Module product, also install the PCIe
cards from your current zl Module.
Serial Numbers
Serial numbers are required when contacting HP or a reseller for warranty
assistance or for coverage under a service agreement. For future reference,
record the serial and product numbers in the warranty booklet that came with
your product.
Each of the HP AllianceONE Services zl Module products ships as a bundle.
From a warranty perspective, a bundle consists of the following separate
hardware components:
■ module
■ HDD
■ CF
Refer to the warranty booklet for warranty coverage details for each hardware
component.
