HP VPN Firewall Appliances Access Control Command Reference

105
Field Descri
p
tion
State-Name Name of a user state.
User-Num Number of users in a specific state.
Message statistics Statistics on messages.
Msg-Name Message type.
Total Total number of messages of a specific type.
Err Number of erroneous messages of a specific type.
Discard Number of discarded messages of a specific type.
MSG_AUTHEN_ACK Authentication acknowledgment message.
MSG_AUTHOR_ACK Authorization acknowledgment message.
MSG_LOGIN_ACK Accounting acknowledgment message.
MSG_LOGOUT_ACK Accounting-stop acknowledgment message.
MSG_LEAVING_ACK Leaving acknowledgment message.
MSG_CUT_REQ Cut request message.
MSG_AUTH_REQ Authentication request message.
MSG_LOGIN_REQ Accounting request message.
MSG_LOGOUT_REQ Accounting-stop request message.
MSG_LEAVING_REQ Leaving request message.
MSG_ARPPKT ARP message.
MSG_PORT_REMOVE Users-of-a-Layer-2-port-removed message.
MSG_VLAN_REMOVE VLAN user removed message.
MSG_IF_REMOVE
Users-removed message, indicating the users on a Layer 3 interface were
removed because the Layer 3 interface was removed.
MSG_IF_SHUT Layer 3 interface shutdown message.
MSG_IF_DISPORTAL Portal-disabled-on-interface message.
MSG_IF_UP Layer 3 interface came up message.
MSG_ACL_RESULT ACL deployment failure message.
MSG_AAACUTBKREQ
Message that AAA uses to notify portal to delete backup user
information.
MSG_CUT_BY_USERINDEX Force-user-offline message.
MSG_CUT_L3IF
Users-removed message, indicating the users on a Layer 3 interface were
removed because they were logged out.
MSG_IP_REMOVE User-with-an-IP-removed message.
MSG_ALL_REMOVE All-users-removed message.
MSG_IFIPADDR_CHANGE Interface IP address change message.
MSG_SOCKET_CHANGE Socket change message.
MSG_NOTIFY Notification message.
MSG_SETPOLICY Set policy message for assigning security ACL.
