HP VPN Firewall Appliances Access Control Command Reference

112
AFF_NTF_USER_NOTIFY 0 0 0
NTF_AUTH 0 0 0
ACK_NTF_AUTH 0 0 0
REQ_QUERY_STATE 0 0 0
ACK_QUERY_STATE 0 0 0
REQ_MACBINDING_INFO 0 0 0
ACK_MACBINDING_INFO 0 0 0
NTF_USER_LOGON 0 0 0
RESERVED33 0 0 0
NTF_USER_LOGOUT 0 0 0
RESERVED35 0 0 0
PT_TYPE_REQ_USER_OFFLINE 0 0 0
Table 33 Command output
Field Descri
p
tion
Interface Interface referencing the portal server.
Server name Name of the portal server.
Invalid packets Number of invalid packets.
Pkt-Name Packet type.
Total Total number of packets.
Discard Number of discarded packets.
Checkerr Number of erroneous packets.
REQ_CHALLENGE Challenge request message the portal server sent to the access device.
ACK_CHALLENGE
Challenge acknowledgment message the access device sent to the portal
server.
REQ_AUTH Authentication request message the portal server sent to the access device.
ACK_AUTH
Authentication acknowledgment message the access device sent to the
portal server.
REQ_LOGOUT Logout request message the portal server sent to the access device.
ACK_LOGOUT
Logout acknowledgment message the access device sent to the portal
server.
AFF_ACK_AUTH
Affirmation message the portal server sent to the access device after
receiving an authentication acknowledgement message.
NTF_LOGOUT
Forced logout notification message the access device sent to the portal
server.
REQ_INFO Information request message.
ACK_INFO Information acknowledgment message.
NTF_USERDISCOVER
User discovery notification message the portal server sent to the access
device.
NTF_USERIPCHANGE
User IP change notification message the access device sent to the portal
server.
AFF_NTF_USERIPCHANGE
User IP change success notification message the portal server sent to the
access device.
