Encryption Key : N/A
VPN instance : N/A
Auth Server Encryption Key : ******
Acct Server Encryption Key : N/A
VPN instance : 1
Accounting-On packet disable, send times : 50 , interval : 3s
Interval for timeout(second) : 3
Retransmission times for timeout : 3
Interval for realtime accounting(minute) : 12
Retransmission times of realtime-accounting packet : 5
Retransmission times of stop-accounting packet : 500
Quiet-interval(min) : 5
Username format : without-domain
Data flow unit : Byte
Packet unit : one
NAS-IP address : 1.1.1.1
Attribute 25 : car
------------------------------------------------------------------
Total 1 RADIUS scheme(s).
Table 40 Command output
Field Descri
p
tion
SchemeName Name of the RADIUS scheme.
Index Index number of the RADIUS scheme.
Type
Type of the RADIUS server that the device supports. Options include:
• Extended—The RADIUS server uses the proprietary RADIUS protocol of
HP for packet exchange.
• Standard—The RADIUS server uses the standard RADIUS protocol for
packet exchange. The protocol is compliant to RFC 2865 and RFC 2866
or later.
Primary Auth Server Information about the primary authentication server.
Primary Acct Server Information about the primary accounting server.
Second Auth Server Information about the secondary authentication server.
Second Acct Server Information about the secondary accounting server.
IP IP address of the server.
Port
Service port of the server. If no port configuration is performed, the default
port number is displayed.
State Status of the server: active or blocked.
Encryption Key
Shared key for secure authentication or accounting communication,
displayed as a series of asterisks (******). If no shared key is configured, this
field displays N/A.
VPN instance
VPN to which the server belongs. If no VPN instance is specified for the
server, this field does not appear.
Probe username Username used for server status detection.
Probe interval Server status detection interval, in minutes.
