HP VPN Firewall Appliances Access Control Command Reference

15
Default command level
2: System level
Parameters
rule-id: Specifies a rule ID, in the range of 0 to 65534. If no rule ID is provided when you create an ACL
rule, the system automatically assigns it a rule ID. This rule ID is the nearest higher multiple of the
numbering step to the current highest rule ID, starting from 0. For example, if the rule numbering step is
5 and the current highest rule ID is 28, the rule is numbered 30.
deny: Denies matching packets.
permit: Allows matching packets to pass.
protocol: Protocol carried by IPv4. It can be a number in the range of 0 to 255, or in words, gre (47),
icmp (1) , igmp (2), ip, ipinip (4), ospf (89), tcp (6), or udp (17) . Table 4 de
scribes the parameters that you
can specif
y regardless of the value for the protocol argument.
Table 4 Match criteria and other rule information for IPv4 advanced ACL rules
Parameters Function Descri
p
tion
source
{ source-address
source-wildcard |
any }
Specifies a source address
The source-address source-wildcard arguments represent
a source IP address and wildcard mask in dotted decimal
notation. An all-zero wildcard specifies a host address.
The any keyword specifies any source IP address.
destination
{ dest-address
dest-wildcard |
any }
Specifies a destination
address
The dest-address dest-wildcard arguments represent a
destination IP address and wildcard mask in dotted
decimal notation. An all-zero wildcard specifies a host
address.
The any keyword represents any destination IP address.
counting
Counts the number of times
the ACL rule has been
matched. In the software
version, the device counts
the number of times the ACL
rule has been matched no
matter whether this keyword
is specified.
N/A
precedence
precedence
Specifies an IP precedence
value
The precedence argument can be a number in the range
of 0 to 7, or in words, routine (0), priority (1), immediate
(2), flash (3), flash-override (4), critical (5), internet (6), or
network (7).
tos tos Specifies a ToS preference
The tos argument can be a number in the range of 0 to 15,
or in words, max-reliability (2), max-throughput (4),
min-delay (8), min-monetary-cost (1), or normal (0).
dscp dscp Specifies a DSCP priority
The dscp argument can be a number in the range of 0 to
63, or in words, af11 (10), af12 (12), af13 (14), af21
(18), af22 (20), af23 (22), af31 (26), af32 (28), af33
(30), af41 (34), af42 (36), af43 (38), cs1 (8), cs2 (16),
cs3 (24), cs4 (32), cs5 (40), cs6 (48), cs7 (56), default (0),
or ef (46).
logging Logs matching packets
This function requires that the module that uses the ACL
supports logging.
