HP VPN Firewall Appliances Access Control Command Reference

16
Parameters Function Descri
p
tion
reflective
Specifies that the rule be
reflective
A rule with the reflective keyword can be defined only for
TCP, UDP, or ICMP packets and can only be a permit
statement.
vpn-instance
vpn-instance-name
Applies the rule to packets in
a VPN instance
The vpn-instance-name argument is a case-sensitive string
of 1 to 31 characters.
If no VPN instance is specified, the rule applies only to
non-VPN packets.
fragment
Applies the rule to only
non-first fragments
Without this keyword, the rule applies to all fragments
and non-fragments.
time-range
time-range-name
Specifies a time range for
the rule
The time-range-name argument is a case-insensitive string
of 1 to 32 characters. It must start with an English letter. If
the time range is not configured, the system creates the
rule. However, the rule using the time range can take
effect only after you configure the timer range.
NOTE:
If you provide the precedence or tos keyword in addition to the dscp keyword, only the dscp keyword
takes effect.
If the protocol argument is tcp (6) or udp (7), set the parameters shown in Table 5.
Table 5 TCP/UDP-specific parameters for IPv4 advanced ACL rules
Parameters Function Descri
p
tion
source-port
operator port1
[ port2 ]
Specifies one or
more UDP or TCP
source ports.
The operator argument can be lt (lower than), gt (greater than), eq
(equal to), neq (not equal to), or range (inclusive range).
The port1 and port2 arguments are TCP or UDP port numbers in the
range of 0 to 65535. port2 is needed only when the operator
argument is range.
TCP port numbers can be represented as: chargen (19), bgp (179),
cmd (514), daytime (13), discard (9), domain (53), echo (7), exec
(512), finger (79), ftp (21), ftp-data (20), gopher (70), hostname
(101), irc (194), klogin (543), kshell (544), login (513), lpd (515),
nntp (119), pop2 (109), pop3 (110), smtp (25), sunrpc (111), tacacs
(49), talk (517), telnet (23), time (37), uucp (540), whois (43), and
www (80).
UDP port numbers can be represented as: biff (512), bootpc
(68),
bootps (67), discard (9), dns (53), dnsix (90)
, echo (7), mobilip-ag
(434), mobilip-mn (435), nameserver (42), netbios-dgm (138),
netbios-ns (137), netbios-ssn (139), ntp (123), rip (520), snmp
(161), snmptrap (162), sunrpc (111), syslog (514), tacacs-ds (65),
talk (517), tftp (69), time (37), who (513), and xdmcp (177).
destination-port
operator port1
[ port2 ]
Specifies one or
more UDP or TCP
destination ports.
{ ack ack-value
| fin fin-value |
psh psh-value |
rst rst-value |
syn syn-value |
urg urg-value }
*
Specifies one or
more TCP flags
including ACK,
FIN, PSH, RST,
SYN, and URG.
Parameters specific to TCP.
The value for each argument can be 0 (flag bit not set) or 1 (flag bit
set).
The TCP flags in a rule are ORed. For example, a rule configured with
ack 1 psh 0 matches both packets with the ACK flag bit set and
packets with the PSH flag bit not set.
