Parameters
zone-name: Specifies the security zone name, a case-insensitive string of 1 to 20 characters that contains
no question mark (?), less-than sign (<), greater-than sign (>), backward slash (\), quotation mark ("),
percentage sign (%), apostrophe ('), ampersand (&), or number sign (#).
zone-id: Specifies the security zone ID.
The following matrix shows the value range for the zone-id argument on different firewalls and firewall
modules:
Hardware Value ran
g
e
F1000-A-EI/F1000-S-EI 0 to 512
F1000-E 0 to 1024
F5000 0 to 1024
F5000-S/F5000-C 0 to 1024
VPN firewall modules 0 to 1024
20-Gbps VPN firewall modules 0 to 1024
Usage guidelines
When creating a security zone, you must specify a security zone name and a security zone ID that are
respectively unique on the VD. To enter the view of an existing security zone, you can specify the security
zone name, or specify both the security zone name and the security zone ID. If you specify both the
security zone name and security zone ID, make sure the two arguments identify the same security zone.
Deleting a security zone deletes the interzone instances that use this zone as the source or destination
zone and the security policies applied to the interzone instances.
System-predefined security zones cannot be deleted.
The security zone ID 0 is used by a system-predefined security zone. You cannot use it for any other
security zone.
Examples
# Create a security zone with the name zonetest and ID 7 for the default VD.
<Sysname> system-view
[Sysname] zone name zonetest id 7
[Sysname-zone-zonetest]
# Create a security zone with the name Zoffice and ID 8 for VD vdtest.
<Sysname> system-view
[Sysname] switchto vdtest
[Sysname-vsys-vdtest] zone name Zoffice id 8
[Sysname-vsys-vdtest-zone-Zoffice]
Related commands
Interzone
