Host name: pc3
Host IP address records
Name: hosttest Status: Out of Use
Host IP addresses: 1.1.1.1, 1.1.1.5
Range IP address records
Name: rangetest Status: Out of Use
Range IP address: 2.2.2.2-2.2.2.20
Exclude IP addresses: 2.2.2.10
Subnet IP address records
Name: subnettest Status: Out of Use
Subnet IP address: 3.3.3.3/0.0.0.255
Exclude IP addresses: 3.3.3.1, 3.3.3.255
Table 13 Command output
Field Descri
p
tion
Host name records
Host address objects that comprise a host name. This field is displayed only
when there is one or more host address objects that comprise a host name.
Host IP address records
Host address objects that comprise host IP addresses. This field is displayed only
when there is one or more host address objects.
Range IP address records
Range address objects. This field is displayed only when there is one or more
range address objects.
Subnet IP address records
Subnet address objects. This field is displayed only when there is one or more
subnet address objects.
Name Object name.
Status
Indicates whether the object is referenced:
• Out of use—Not referenced.
• In use—Referenced.
Description
Description for the object. This field is displayed only when a description is
configured for the object.
Host IP addresses Host IP address members.
Host name Host name member.
Range IP address Range address member.
Subnet IP address Subnet address member.
Exclude IP addresses
IP addresses excluded from the IP address range or subnet IP address. This field
is displayed only when one or more IP addresses are excluded from an IP
address range or subnet IP address.
display object-group
Use display object-group to display group objects.
