HP VPN Firewall Appliances Access Control Command Reference

39
Syntax
display object-group { mac | name object-group-name | network | service } [ vd vd-name ]
Views
Any view
Default command level
1: Monitor level
Parameters
mac: Displays MAC address group objects.
name object-group-name: Displays a specific group object. The object-group-name argument is a
case-insensitive string of 1 to 31 characters.
network: Displays IP address group objects.
service: Displays service group objects.
vd vd-name: Displays the group objects of a VD. The vd-name argument is a case-insensitive string of 1
to 20 characters. If you do not specify this option, group objects of the default VD are displayed.
Examples
# Display all MAC address group objects on the default VD.
<Sysname> display object-group mac
1 records in total for VD root.
Name: groupmac Status: Out of use
Description: objectgroup-mac-desc
Objects: objectmac1, objectmac2
# Display the group object groupaddr on the default VD.
<Sysname> display object-group name groupaddr
Object type: Network object group
VD name: root
Name: groupaddr Status: Out of use
Description: objectgroup-network-desc
Objects: objectaddr1, objectaddr2
Table 14 Command output
Field Descri
p
tion
Object type
Group object type:
• Network object group—IP address group object.
• MAC object group—MAC address group object.
• Service object group—Service group object.
VD name VD name. The name of the default VD is root.
Name Object name.
Status
Indicates whether the object is referenced:
• Out of use—Not referenced.
• In use—Referenced.
