HP VPN Firewall Appliances Access Control Command Reference

52
Description: forprotocol2
Protocol: Other Protocol Number: 2
Name: icmp Status: Out of Use
Protocol: ICMP Type: 20 Message Code: 30
Name: tcp Status: Out of Use
Protocol: TCP Source Port: Any Destination Port: 100-200
Table 15 Command output
Field Descri
p
tion
Name Object name.
Status
Whether the object is referenced:
• Out of use—Not referenced.
• In use—Referenced.
Description
Description for the object. This field is displayed only when a description is configured for
the object.
Protocol
Member of the object. Possible values include ICMP, UDP, TCP, and Other. This field is
displayed only when a protocol is added to the object.
Source Port Source port of the protocol. This field is displayed only when the protocol is TCP or UDP.
Destination Port
Destination port of the protocol. This field is displayed only when the protocol is TCP or
UDP.
Type ICMP message type. This field is displayed only when the protocol is ICMP.
Code ICMP message code. This field is displayed only when the protocol is ICMP.
Protocol number
Number of the protocol added to the service object. This field is displayed only when the
value of the Protocol field is Other.
display object service default
Use display object service default to display system pre-defined service objects.
Syntax
display object service default
Views
Any view
Default command level
1: Monitor level
Usage guidelines
The system pre-defined service objects cannot be deleted or changed, and are available for all VDs.
The device supports 98 system pre-defined service objects.
Examples
# Display system pre-defined service objects on the default VD.
<Sysname> display object service default
