Figure 78 MLDv2 query message format
Table 15 MLDv2 query message field description
Field Descri
p
tion
Type = 130 Message type. For a query message, this field is set to 130.
Code Initialized to zero.
Checksum Standard IPv6 checksum.
Maximum Response Delay Maximum response delay allowed before a host sends a report message.
Reserved Reserved field and initialized to zero.
Multicast Address
• This field is set to 0 in a general query message.
• It is set to a specific IPv6 multicast address in a
multicast-address-specific query message or
multicast-address-and-source-specific query message.
S
Flag indicating whether a router updates the timer for suppression after
receiving a query message.
QRV Querier's Robustness Variable.
QQIC Querier's Query Interval Code.
Multicast Address (128 bits)
Type = 130 Code
07 15 31
Checksum
Maximum Response Delay Reserved
Reserved S QRV QQIC Number of Sources (n)
34
Source Address [1] (128 bits)
Source Address [n] (128 bits)
