Riverbed® Steelhead® RiOS® Application Installation and Getting Started Guide 2010-10

2-1
2
Hardware Installation
The HP AllianceONE Extended Services zl Module with the Riverbed
®
Steelhead
®
RiOS
®
Application is designed to run in an HP 5400zl or 8200zl
Series Switch. Table 2-1 lists the tasks that you will perform to get the HP
AllianceONE Extended Services zl Module up and running so that you can
begin the initial configuration process (as outlined in Chapter 3: “Getting
Started”).
If the HP 5400zl or 8200zl switch has already been installed, move to “Update
the Switch Software” on page 2-4.
Table 2-1. Installation Process
Hardware Overview
The Extended Services zl Module requires two open slots in the 5400zl or
8200zl switch chassis. For a description of the front panel buttons and LEDs,
which are identified in Figure 2-1, see Table C-1 on page C-2 in the Web version
of this document at www.hp.com/networking/manuals.
Estimated Time Task Reference
30 minutes Install the HP switch (if not already
installed)
Installation and Getting Started Guide for the HP ProCurve
Series 5400zl Switches shipped with your equipment
10 minutes Update the HP switch software “Update the Switch Software” on page 2-4
2 minutes Set the HP switch time “Set the Switch Time” on page 2-7
5 minutes
(and 10 minutes for
initial bootup)
Install the Extended Services zl
Module in the HP switch
“Install the Extended Services zl Module” on page 2-10
10 minutes Complete initial setup in the HP
switch
Chapter 3: “Getting Started”
