2-13
Hardware Installation
Environmental Specifications
Environmental Specifications
Table 2-3 lists the maximum temperatures and other environmental specifica-
tions for Extended Services zl Modules.
Table 2-3. Environmental Specifications
Temperature Operating
0C to 45C (32F to 113F)
1
1. For the 5406zl/8206zl chassis, a maximum of two Extended Services zl Modules may be
installed, one on either side of the chassis.
For the 5412zl chassis, a maximum of four Extended Services zl Modules may be installed;
three of these modules may be installed in the left side of the chassis. If a module is installed
in excess of these quantities, the module will not boot.
For the 8212zl chassis, a maximum of four Extended Services zl Modules may be installed;
two of these modules may be installed in the left side of the chassis.
For the 5400zl chassis, if all the modules are installed in the left side of the chassis the
temperature specification is set to 50°C for the chassis. If any modules are installed on the
right side of the chassis, then the temperature specification for the chassis is 45°C.
Non-Operating
-10C to 65C (-10F to 149F)
Relative humidity
(non-condensing)
15% to 90% at 40C (104F) 15% to 90% at 65C (149F)
Maximum altitude 3.0 km (10,000 ft) 4.6 km (15,000 ft)
