TMS zl Module Release Notes ST.1.2.100916
Table Of Contents
- Release Notes: Version ST.1.2.100916 Software for the HP ProCurve Threat Management Services zl Module
- Contents
- Software Management
- Download Documentation from the Web
- Software Updates
- Special Considerations Prior to Updating
- Clarifications
- Enhancements
- Enhancements in ST.1.2.100916
- ST.1.1.100430
- ST.1.1.100226
- Command Line Interface (CLI) control of VPN functionality
- RADIUS authentication for management logins
- RADIUS authentication for L2TP users
- Renaming zones
- 256 VLANs now supported, increased from 19 VLANs
- Enhanced sort and filter capabilities for displaying log files
- Improved SNMP Monitoring for network traffic and key system resources
- Software Fixes in Releases ST.1.0.090213 - ST.1.2.100916
- Known Issues
82
Known Issues
Release ST.1.0.090213
■ PR_961 — The initial login banner text of the Web browser interface in the TMS zl Module
differs in size depending on whether the user is accessing it with HTTP or HTTPS. While
noticeable, this difference in size does not impair functionality.
■ PR_1044 — From the TMS zl Module CLI, when a TMS zl Module is operating in Routing
Mode using OSPF, the command show ip ospf neighbor has an output that is not the same as
a ProCurve switch that is running OSPF. Important information about OSPF neighbors is still
shown, how the information that is shown is different from the switch.
■ PR_1143 — The options for VLAN IPv4 functionality change depending on how a command
is accessed. For example, vlan <id> ip options are different than going into the VLAN context
via vlan <id> and then typing ip.
Example:
ProCurve Switch(tms-module-D:config)# vlan 20 ip
address Set IP parameters for communication within an IP network.
igmp Enable IGMP on the VLAN.
pim-sparse Enable PIM-SM on the device.
ProCurve Switch(tms-module-D:config)# vlan 20
ProCurve Switch(tms-module-D:vlan-20)# ip
address Set IP parameters for communication within an IP network.
igmp Enable IGMP on the VLAN.
rip Configure RIP on the VLAN.
ospf Configure OSPF settings.
pim-sparse Enables PIM-SM on the VLAN.
The impact to the user is that some commands cannot be typed in a single line and the VLAN
configuration context must be entered in order to configure some items.
■ PR_3186 — From the CLI, the schedule command does not auto-complete when the Tab
key is pressed as other commands from the command line do.
For example, the following command will not auto-complete to daily when the Tab key is pressed
after only dail is typed:
ProCurve Switch(tms-module-D:config)#schedule time1 dail
The impact to the user is that the entire parameter must be typed out.
■ PR_4155 — The two internal Ethernet ports of the TMS zl Module have an actual speed of
10Gbps. However, in the SNMP MIB, they are reported as 10Mbps. This issue only affects the
reporting of the speed via SNMP. The actual speed is 10Gbps.
■ PR_4266 — There is a discrepancy between the Web browser interface and the CLI in
regards to how the subnet mask is specified in a static route configuration. The CLI requires
the subnet mask to be specified in dotted decimal format while the Web browser interface
uses CIDR addresses. No functionality is impacted.
