A-16
ProCurve Wireless Services xl Module Command Line Reference
Manager Commands
debug pktdrvr
This command traces pktdrvr (kernel wireless) debugging messages. The no
command negates the trace.
Syntax
debug pktdrv (debug | err | info | rate-limit | warn | all)
• debug - Trace all messages from the pktdrvr.
• err- Trace error messages from the pktdrvr. Default if no parameter is
specified.
• info - Trace error, warning, and informational messages from the pktdvr.
• rate-limit - Trace rate-limiting log messages from the pktdvr.
• warn- Trace error and warning messages from the pktdvr.
Default Setting
debug pktdrv err
Command Mode
Manager
Example
debug pm
This command traces process monitor debugging messages. The no command
negates the trace.
Syntax
debug pm ( all | errors | heartbeats | init | proc | shutdown | subagent | sys )
• all - Trace all process monitor messages. The no version of the command
negates the trace.
• errors- Trace process monitor error messages . The no version of the
command negates the trace.
• heartbeats- Trace heartbeats process messages. The no version of the
command negates the trace.
• init- Trace initialization process messages. The no version of the command
negates the trace.
ProCurve(wireless-services-B)#debug pktdrv rate-limit
ProCurve(wireless-services-B)#
