Technical white paper

Solid State Drive Technology

Differences between SLC, MLC and TLC NAND

Table of contents

Executive summary .............................................................................................................................................. 2

SLC vs MLC vs TLC ................................................................................................................................................. 2

NAND cell technology ....................................................................................................................................... 2

Write amplification ............................................................................................................................................ 2

Write endurance ................................................................................................................................................ 2

SMART technology ............................................................................................................................................ 4

Cost per gigabyte .............................................................................................................................................. 4

Conclusion .............................................................................................................................................................. 4

References ............................................................................................................................................................. 4

For more information ........................................................................................................................................... 5

Summary of content (5 pages)

PAGE 1
Technical white paper Solid State Drive Technology Differences between SLC, MLC and TLC NAND Table of contents Executive summary .............................................................................................................................................. 2 SLC vs MLC vs TLC ................................................................................................................................................. 2 NAND cell technology .................................................
PAGE 2
Technical white paper | Solid State Drive Technology Executive summary This document outlines the differences between three different NAND technologies: SLC, MLC, and TLC. • SLC - Single level cell provides high performance, low power consumption; faster write speeds, and higher program/erase cycles per cell, but at a higher cost. These devices are mainly used in high end server applications.
PAGE 3
Technical white paper | Solid State Drive Technology Table 1. Write endurance SLC MLC TLC Bits per cell 1 2 3 P/E Cycles 100,000 3,000 1,000 Read Time 25us 50us ~75us Program Time 200-300us 600-900us ~900-1350us Erase Time 1.5-2ms 3ms ~4.5ms SLC NAND flash typically rates endurance at about 100K cycles. MLC NAND flash is typically rated about 3K-5K cycles. TLC NAND flash is typically rated about 1K-3K cycles.
PAGE 4
Technical white paper | Solid State Drive Technology Figure 1: Block copy time *note: tProg = program time SMART technology S.M.A.R.T (Self-Monitoring, Analysis and Reporting Technology) is standard in all storage devices. It monitors fault conditions and decreases the chance of data loss by giving adequate warning to these conditions. Some of the many attributes that are reported include re-allocated NAND block count and wear leveling count.
PAGE 5
Technical white paper | Solid State Drive Technology For more information For current HP driver, support, and security alerts delivered directly to your desktop, go to hp.com/go/getconnected. To help us improve our documents, please provide feedback at hp.com/solutions/feedback. Sign up for updates hp.com/go/getupdated © Copyright 2013 Hewlett-Packard Development Company, L.P. The information contained herein is subject to change without notice.
