HP ProLiant BL680c G7 Server Blade Maintenance and Service Guide

Removal and replacement procedures 52
3.
Install the heatsink.
4. Install the front panel/hard drive cage assembly (B-side) ("Front panel/hard drive cage assembly
(B-side)" on page 43).
5. Install the hard drives ("Hard drive" on page 41).
6. Install the hard drive blanks ("Hard drive blank" on page 41).
7. Install the access panel (B-side) ("Access panel (B-side)" on page 32).
8. Install the server blade ("Installing a server blade" on page 30).
9. Power up the server blade.
Processor (A-side)
WARNING: To reduce the risk of personal injury from hot surfaces, allow the drives and the
internal system components to cool before touching them.
CAUTION: To prevent possible server blade malfunction and damage to the equipment,
multiprocessor configurations must contain processors with the same part number.
CAUTION: The heatsink thermal interface media is not reusable and must be replaced if the
heatsink is removed from the processor after it has been installed.
IMPORTANT: Processor socket 1 must be populated at all times or the server blade does not
function.
To remove the component:
1. Power down the server blade (on page 28).
2. Remove the server blade (on page 29).
3. Remove the access panel (A-side) ("Access panel (A-side)" on page 31).
4. Remove all hard drives ("Hard drive" on page 41).
5. Remove all hard drive blanks ("Hard drive blank" on page 41).
