ProLiant DL360

Server Architecture........12

Processor/Memory

Subsystem...........................12

I/O Subsystem.....................13

Power Subsystem ................14

Conclusion.....................15

Compaq



 ProLiant



 DL360 Server

Technology

Ultra-Dense Servers for Rack Environments

BSTRACT

Rapid growth of application service providers (ASPs) and Internet service providers

(ISPs) fuels demand for ultra-dense servers in rack environments. Through innovative

mechanical and electrical design, Compaq has developed a high-performance 1U server

ideal for dedicated applications or web hosting. The highly modular Compaq ProLiant

DL360 server is a total, high-density solution for any computing environment, from the

data center to remote locations. Compaq provides multiple deployment option kits for

rapid, high-volume installation of ProLiant DL360 servers in Compaq 9000-Series and

7000-Series racks, in telecommunication (Telco) racks, in standard third-party racks, and

as desktop/stackable units. Compaq also provides written guidelines for deploying the

server most effectively using each option.

This field brief explains the technology innovations that significantly increase

serviceability and enable easy installation of up to 42 full-featured ProLiant DL360

servers in a standard 42U rack.

Please direct comments regarding this communication to the ISSD Technology Communications Group at this internet

address: TechCom@compaq.com

Summary of content (15 pages)

PAGE 1
TECHNOLOGY BRIEF June 2000 Compaq Computer Corporation ISSD Technology Communications CONTENTS Introduction .....................3 Unique Mechanical and Electrical Design..............................3 1U Geometry ......................... 4 Unique Thermal Design .......... 5 Virtually No Internal Cables .... 6 Tool-Free Serviceability ......... 7 Total Solution for any Computing Environment ....................9 Fixed Rack Rails .................... 9 Slide Rails and Cable Management Solution ..........
PAGE 2
TECHNOLOGY BRIEF (cont.) .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. . TC000601TB 2 Compaq ProLiant DL 360 Server Technology NOTICE The information in this publication is subject to change without notice and is provided “AS IS” WITHOUT WARRANTY OF ANY KIND.
PAGE 3
TECHNOLOGY BRIEF (cont.) 1U: 1.65 inches (4.19 centimeters) TC000601TB .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. . 3 Compaq ProLiant DL 360 Server Technology INTRODUCTION The e-commerce explosion is forcing businesses to upgrade their enterprise computing systems to remain competitive.
PAGE 4
TECHNOLOGY BRIEF (cont.) DIMM: dual inline memory module PCI: peripheral component interface PCI riser board assembly TC000601TB .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .
PAGE 5
TECHNOLOGY BRIEF (cont.) .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. . TC000601TB 5 Compaq ProLiant DL 360 Server Technology Unique Thermal Design The most difficult obstacle Compaq overcame in designing the 1U server was devising a way to cool server components adequately in such a densely packed chassis.
PAGE 6
TECHNOLOGY BRIEF (cont.) SCSI backplane LED: light-emitting diode TC000601TB .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. . 6 Compaq ProLiant DL 360 Server Technology By positioning all fans near the middle of the ProLiant DL360 server, Compaq maximized thermal performance and minimized fan noise.
PAGE 7
TECHNOLOGY BRIEF (cont.) .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. . TC000601TB 7 Compaq ProLiant DL 360 Server Technology An internal ribbon cable connecting the CD-ROM/floppy drive assembly to the system board lies flat under the power supply.
PAGE 8
TECHNOLOGY BRIEF (cont.) NIC: network interface controller TC000601TB .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. . 8 Compaq ProLiant DL 360 Server Technology Unit Identification LED Unit Identification Switch Unit Identification Switch and LED Figure 4.
PAGE 9
TECHNOLOGY BRIEF (cont.) Telco: telecommunications Rear view of ProLiant DL360 server installed with standard fixed rack rails TC000601TB .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .
PAGE 10
TECHNOLOGY BRIEF (cont.) .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. . Rear view of ProLiant DL360 ... .. server installed with slide . rails and cable management ... .. solution option kit .. .. .. .. .. .. .. .. .. .. .. .. .. Rack Frame .. .. .. 5.625" 19.375" .. .. .. .. Server .. .. .. .. .. ProLiant DL360 server .. in Telco rack .. .. .. .. .. .. .. .. .. .. .
PAGE 11
TECHNOLOGY BRIEF (cont.) Stacked ProLiant DL360 servers TC000601TB .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. . 11 Compaq ProLiant DL 360 Server Technology For Telco rack installation, it should be noted that the ProLiant DL360 Server does not support a 48-volt power supply.
PAGE 12
TECHNOLOGY BRIEF (cont.) .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. . TC000601TB 12 Compaq ProLiant DL 360 Server Technology When installed in a server, the Remote Insight Lights-Out Edition eliminates the requirement for equipping that server with a keyboard, mouse, and monitor.
PAGE 13
TECHNOLOGY BRIEF (cont.) TC000601TB 13 The ServerSet III chip set uses low-latency PC133 registered error checking and correcting SDRAM (3.3V, 133 MHz).2 Integrated voltage regulators provide the required voltages for both processors and chip set. The PCI/memory controller (north bridge) supports up to four doublesided DIMMs for a maximum system memory capacity of 4 GB (using 1-GB DIMMS). The server ships standard with a single 128-MB SDRAM module in one of four DIMM sockets.
PAGE 14
TECHNOLOGY BRIEF (cont.) SGRAM: synchronous graphic random access memory VHDCI: very high density cable interconnect TC000601TB .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. . 14 Compaq ProLiant DL 360 Server Technology Smart Array Controller the SCSI bus master (Figure 7).
PAGE 15
TECHNOLOGY BRIEF (cont.) .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. . TC000601TB 15 Compaq ProLiant DL 360 Server Technology CONCLUSION The Compaq ProLiant DL360 server provides a total, high-density solution for any computing environment, from the data center to remote locations.
