HP ProLiant DL360p Gen8 Server Maintenance and Service Guide
Table Of Contents
- HP ProLiant DL360p Gen8 Server Maintenance and Service Guide
- Abstract
- Notice
- Contents
- Customer self repair
- Illustrated parts catalog
- Removal and replacement procedures
- Required tools
- Preparation procedures
- Safety considerations
- Access panel
- Drive blank
- Hot-plug drive
- Power supply blank
- AC power supply
- 48V DC power supply option
- Drive cage assembly
- DVD-ROM or DVD-RW drive
- Fan module
- Fan blank
- Flash-backed write cache procedures
- Front video adapter
- FlexibleLOM
- Rack bezel
- Air baffle
- PCI riser cage
- Expansion boards
- PCIe riser board
- DIMMs
- Heatsink
- Processor
- System battery
- System board
- HP Trusted Platform Module
- Cabling
- Diagnostic tools
- Component identification
- Specifications
- Environmental specifications
- Server specifications
- Power supply specifications
- HP 460W Common Slot Gold Hot Plug Power Supply (92% efficiency)
- HP 460W Common Slot Platinum Plus Hot Plug Power Supply (94% efficiency)
- HP 500W Common Slot 277VAC Hot Plug Power Supply (94% efficiency)
- HP 750W Common Slot 277VAC Hot Plug Power Supply (94% efficiency)
- HP 750W Common Slot Titanium Hot Plug Power Supply (96% efficiency)
- HP 750W Common Slot Gold Hot Plug Power Supply (92% efficiency)
- HP 750W Common Slot Platinum Plus Hot Plug Power Supply (94% efficiency)
- HP 750W Common Slot -48VDC Hot Plug Power Supply (94% efficiency)
- HP 1200W Common Slot Platinum Plus Hot Plug Power Supply (94% efficiency)
- Hot-plug power supply calculations
- Acronyms and abbreviations
- Documentation feedback
- Index
Illustrated parts catalog 22
Item Description
Spare part
number
Customer self
repair (on
page
5
)
j) 400-GB, SATA, MLC SSD, 6.35 cm (2.5 in)* 653967-001 Mandatory
1
k) 400-GB, SATA, MLC SSD, 8.89 cm (3.5 in)* 653970-001 Mandatory
1
l) 400-GB, SAS, MLC SSD, 6.35 cm (2.5 in)* 653963-001 Mandatory
1
m) 400-GB, SAS, SLC SSD, 6.35 cm (2.5 in)* 653962-001 Mandatory
1
n) 450-GB, SAS, 6.35 cm (2.5 in)* 653956-001 Mandatory
1
o) 450-GB, SAS, 8.89 cm (3.5 in)* 653951-001 Mandatory
1
p) 500-GB, SAS, 6.35 cm (2.5 in)* 653953-001 Mandatory
1
q) 500-GB, SATA, 6.35 cm (2.5 in)* 656107-001 Mandatory
1
r) 500-GB, SATA, 8.89 cm (3.5 in)* 658103-001 Mandatory
1
s) 600-GB, SAS, 6.35 cm (2.5 in)* 653957-001 Mandatory
1
t) 600-GB, SAS, 8.89 cm (3.5 in)* 653952-001 Mandatory
1
u) 800-GB, SAS, MLC SSD, 6.35 cm (2.5 in)* 653964-001 Mandatory
1
v) 900-GB, SAS, 6.35 cm (2.5 in)* 653971-001 Mandatory
1
w) 1-TB, SAS, 6.35 cm (2.5 in)* 653954-001 Mandatory
1
x) 1-TB, SAS, 8.89 cm (3.5 in)* 653947-001 Mandatory
1
y) 1 TB, SATA, 6.35 cm (2.5 in)* 656108-001 Mandatory
1
z) 1-TB, SATA, 8.89 cm (3.5 in)* 657739-001 Mandatory
1
aa) 2-TB, SAS, 8.89 cm (3.5 in)* 653948-001 Mandatory
1
bb) 2-TB, SATA, 8.89 cm (3.5 in)* 658102-001 Mandatory
1
cc) 3-TB, SAS, 8.89 cm (3.5 in)* 653959-001 Mandatory
1
dd) 3-TB, SATA, 8.89 cm (3.5 in)* 628182-001 Mandatory
1
Options — —
19
Cache module* — —
a) FBWC module, 512-MB 633540-001 Optional
2
b) FBWC module, 1-GB 633542-001 Optional
2
c) FBWC module, 2-GB 633543-001 Optional
2
20
FBWC capacitor pack, 91 cm (36 in) 671353-001 Optional
2
21
PCI riser board options* — —
a) PCIe riser board, x8, LP 667866-001 Optional
2
b) PCIe riser board, x16, FH, HL 667867-001 Optional
2
Miscellaneous — —
22
HP Trusted Platform Module* 450168-001 No
3
23
Battery, 3.3-V, lithium* 234556-001 Mandatory
1
24
AC power cord* 187335-001 Mandatory
1
Cables — —
