Specifications 93
HP 750W Common Slot Titanium Hot Plug Power Supply (96%
efficiency)
Specification Value
Input requirements
—
Rated input voltage
200 to 240 V AC
Rated input frequency
50 Hz to 60 Hz
Rated input current
4.1 A at 200 V AC
3.3 A at 240 V AC
Maximum rated input power
820 W at 200 V AC
792 W at 240 V AC
Btus per hour
2739 at 200 V AC
2724 at 240 V AC
Power supply output
—
Rated steady-state power
750 W at 200 V AC to 240 V AC
input
Maximum peak power
750 W at 200 V AC to 240 V AC
input
HP 750W Common Slot Gold Hot Plug Power Supply (92%
efficiency)
Specification Value
Input requirements
Rated input voltage
100 to 120 VAC, 200 to
240 VAC
Rated input frequency
50 Hz to 60 Hz
Rated input current
8.9 A at 100 VAC
4.3 A at 200 VAC
Rated input power
857 W at 100V AC input
824 W at 200V AC input
BTUs per hour
2925 at 100V AC input
2812 at 200V AC input
Power supply output
Rated steady-state power
750 W at 100V to 120V AC input
750 W at 200V to 240V AC input
Maximum peak power
750 W at 100V to 120V AC input
750 W at 200V to 240V AC input
