ProLiant DL580 Generation 3 Server Maintenance and Service Guide

Illustrated parts catalog 9
Item Description
Original
assembly part
number
Modified
assembly part
number
Original
spare part
number
Modified
spare part
number
Customer self
repair
8
Media board
(CD/DVD/diskette)
012207-
001‡ See
requirement
012207-501
376477-
001‡ See
requirement
416422-001 Yes
9
Power backplane,
ProLiant DL580
G3 Server *
012110-
001‡ See
requirement
012110-501
376476-
001‡ See
requirement
411795-001 No
10
Processor module
assembly, ProLiant
DL580 G3 Server
012095-
001‡ See
requirement
012095-501
376469-
001‡ See
requirement
412325-001 Yes
11
Processor Power
Module
367240-001 —
370718-
001‡ See
requirement
— Yes
12
Memory board,
ProLiant Dl580 G3
Server
012098-
001‡ See
requirement
012825-001
376470-
001‡ See
requirement
410188-001 Yes
— Media devices — — — — —
13
Diskette drive, 3.5
in
263394-
001‡ See
requirement
263394-002
263394-
002‡ See
requirement
399396-001 Yes
14 DVD drive, 8x
168003-
9D1/935‡
See
requirement
395910-001
395910-
001‡ See
requirement
397928-001 Yes
15
DVD/CD-RW drive
*
294766-
9D1/9D2‡
See
requirement
383696-002
337273-
001‡ See
requirement
399959-001 Yes
— Hard drives — — — — —
16
SCSI Ultra320
universal hot-plug
hard drive
— — — — —
—
a) 36.4 GB,
15,000 rpm *
271837-
016‡ See
requirement
404670-008
289241-
001‡ See
requirement
404714-001 Yes
—
b) 72.8 GB,
10,000 rpm *
271837-
008‡ See
requirement
404670-003
289042-
001‡ See
requirement
404709-001 Yes
—
c) 72.8 GB,
15,000 rpm *
271837-
018‡ See
requirement
404670-007
289243-
001‡ See
requirement
404713-001 Yes
—
d) 146.8 GB,
10,000 rpm *
271837-
010‡ See
requirement
404670-002
289044-
001‡ See
requirement
404708-001 Yes
—
e) 146.8 GB,
15,000 rpm *
281837-
028‡ See
requirement
404670-006
347779-
001‡ See
requirement
404712-001 Yes
—
f) 300 GB,
10,000 rpm *
271837-
001‡ See
requirement
404670-001
351126-
001‡ See
requirement
404701-001 Yes
