Compaq ProLiant ML330 Server Overview

Compaq Proliant ML330
Rev. 0.42 1 of 4
Compaq ProLiant ML330 Server Overview
Description
The ProLiant ML330 is the entry server into the ProLiant family. This update
offers the latest available 1Ghz Intel Pentium III processor technology.
Note
Although it is physically possible to install a 1GHz processor in previous
models of the ProLiant ML330, Compaq does not support this upgrade
because of potential thermal problems.
New Models
The following table provides the part numbers and configuration codes for the
updated ProLiant ML330:
Table 1: Part Numbers and Configuration Codes
Server Model Part Number Configuration Code
ML330T01 P1000-256K 128 MB 161411-XX1 JBY1
ML330T01 P1000-256K 128 MB 9.1GB HD 161411-XX2* JBY2
* Not available in North America
New Features
The new server now has a 1.0GHz processor; otherwise, there are no feature
differences between the new model and its predecessors.
Switch Settings
Table 2 lists the new SW1 settings for the 1.0GHz processor.
Table 2: SW1 Switch Settings
Positions Switch
Number S2 S3 S4 S5
SW1 OFF ON OFF OFF
Options
Processor option kits for updating to latest processor technologies are not being
offered on any of the existing Compaq ProLiant ML330 models.
The new options supported by the Compaq ProLiant ML330 are shown in Table 3.
