Illustrated Parts List 1-3
External Components—Spare Parts List
Table 1-1
External Components Spare Parts List
Item Description Spare Part Number
Chassis
1 Chassis, rack-mount 159316-001
2 Cover kit, rack-mount 167122-001
a) Rack-mount bezel
b) Access panel
3 Power On/Standby switch with LEDs and cable 161659-001
Mass Storage Devices
4 Diskette drive, 1.44 MB 123958-001
5 CD-ROM drive 327659-001
6 Hard drive cage blanking panel 159311-001
7 Hard drive cage with backplane board (maximum: 2 per unit) 159313-001
8 Hot-plug hard drive (maximum: 12 per unit)
9.1 GB hot-plug Wide Ultra2 SCSI hard drive, 7200 rpm 104665-001
9.1 GB hot-plug Wide Ultra2 SCSI hard drive, 10,000 rpm 386536-001
9.1 GB hot-plug Wide Ultra3 SCSI hard drive, 10,000 rpm 152188-001
9.1 GB hot-plug Wide Ultra3 SCSI hard drive, 15,000 rpm 189393-001
18.2 GB hot-plug Wide Ultra2 SCSI hard drive, 7200 rpm 104663-001
18.2 GB hot-plug Wide Ultra2 SCSI hard drive, 10,000 rpm 143920-001
18.2 GB hot-plug Wide Ultra3 SCSI hard drive, 10,000 rpm 152190-001
18.2 GB hot-plug Wide Ultra3 SCSI hard drive, 15,000 rpm 189351-001
36.4 GB hot-plug Wide Ultra3 SCSI hard drive, 10,000 rpm 177986-001
9 Hard drive blank (maximum: 12 per unit) 122759-001
Power Supplies
10 Hot-plug power supply, 450 W (maximum: 3 per unit) 157793-001
11 Power supply blanking panel (maximum: 2 per unit) 159310-001
Note: The tower chassis model is listed under “Hardware” in Table 1-2.
