3-60 Compaq ProLiant ML530 Servers Maintenance and Service Guide
The following ASR-2 flow chart shows you the sequence of events after a hardware or software
error occurs:
Hardware/Software error occurs.
Error is recorded in the Critical Error
Log or the Integrated Management
Log, depending on the server
configuration.
Operating system halts normal
operation.
ASR timer expires.
Server is reset.
If a modem is installed and paging is
enabled, the Server Failure
Notification pager alert is sent to the
Server Administrator.
Unattended server starts the
operating system.
—Or— Server starts Compaq Utilities from
the system partition on the
hard drive.
If the server continues to experience
hardware/software errors and the
number of ASR cycles exceeds the
specified number of recovery
attempts, the server logs an error to
the Server Health Log or the
Integrated Management Log and
boots the Compaq Utilities from the
system partition on the hard drive.
If a modem is installed, ASR puts
the modem on autoanswer so that
the server administrator can dial in
(using third-party terminal emulator
software) to remotely run the
Compaq Utilities to identify the
source of the fault.
Or
Local Server Administrator runs
Compaq Utilities from the server
console to identify the source of
the fault.
Figure 3-2. ASR-2 flow chart
