ProLiant ML530 Servers Maintenance and Service Guide

Diagnostics and Troubleshooting 3-63
Table 3-23
Compaq System Configuration Utility Pager Settings for Booting into Compaq Utilities
continued
Pager Data Setting Description
Network host
name
CPQHOU Enter the network name of the server. Use underscores instead of
spaces within the name, for example, Compaq_Server. If you are using
IPX network access to the Compaq Utilities, this server name is used to
advertise NVT host services. This server name displays in the Compaq
Insight Manager server list when the program determines it can
communicate using NVT. Set this name to be the same as the server
name you assign when the host OS is running.
Network card
slot
Slot # Select the slot number of the network interface card you wish to use for
network access to Compaq Utilities.
Network frame
type
ETHERNET_I I Select the frame type for the network. Selections include both Ethernet
and Token Ring topologies.
Network IP
address
Enter the IP address for this server in standard dot notation.
Note: This address is not used if you select Custom for Network
controller. You must enter the IP address in the NET.CFG file that you
load into the system partition.
Network IP net
mask
Enter the net mask for this server in standard dot notation.
Note: This address is not used if you select Custom for network
controller. You must enter the IP address in the NET.CFG file that you
load into the system partition.
Network IP
router address
Enter the router address to be used for this server in standard dot
notation.
Note: This address is not used if you select Custom for network
controller. You must enter the IP address in the NET.CFG file that you
load into the system partition.
If you configure the server to boot into Compaq Utilities, it prepares for remote
communications. You can remotely run Diagnostics software, the Inspect Utility, or the System
Configuration Utility using a workstation running terminal emulation software such as Compaq
Insight Manager or PC Anywhere.
Booting into the Operating System
When you enable ASR-2 to restart into the operating system and a critical error occurs, ASR-2
logs the error in the Critical Error Log or IML and restarts the server. The system ROM pages
the designated administrator, then executes the normal restart process.
IMPORTANT: When you enable ASR-2 to restart into the operating system, Modem Dial-In Status,
Network Status, and Modem Dial-Out Status are automatically disabled. In this mode, ASR-2 can page
you if a critical error occurs, but you cannot access the server, and the server cannot dial out to a remote
workstation.
If the ASR-2 feature cannot restart the server within 10 attempts, it logs a critical error in the
Critical Error Log or IML, restarts the server into the Compaq Utilities, and puts the modem
into auto-answer mode.
