ProLiant ML530 Servers Maintenance and Service Guide

Illustrated Parts List 1-5
System Components—Spare Parts List
Table 1-2
System Components Spare Parts List
Item Description Spare Part Number
Boards
12 Power backplane board 159314-001
13 System board tray 159301-001
14 10/100 PCI network interface controller (NIC) 174831-001
Memory
15 Memory modules, 133-MHz, ECC SDRAM DIMM (maximum: 8 per unit)
64-MB SDRAM, 64 megabit memory module 159225-001
128-MB SDRAM, 64 megabit memory module 159226-001
128-MB SDRAM, 128 megabit memory module 164278-001
256-MB SDRAM, 64 megabit memory module 159304-001
256-MB SDRAM, 128 megabit memory module 159377-001
512-MB SDRAM, 128 megabit memory module 159227-001
512-MB SDRAM, 256 megabit memory module 177628-001
Processor
16 Processor with gold-colored heat sink (maximum: 2 per unit)
800-MHz processor with gold-colored heat sink 167121-001
866-MHz processor with gold-colored heat sink 187528-001
933-MHz processor with gold-colored heat sink 187529-001
1-GHz processor with gold-colored heat sink 217045-001
Fans
17 Hot-plug drive fan (maximum: 3 per unit) 161657-001
18 Hot-plug system fan (maximum: 4 per unit) 171531-001
19 System fan basket (maximum: 2 per unit) 161658-001
20 Miscellaneous hardware kit 159321-001
a) Removable media bay blanking panel, shown in Figure 1-1 (maximum: 2 per unit)
b) System fan basket-and-cable bracket with cable (maximum: 2 per unit)
21 Miscellaneous plastics kit 159322-001
a) CPU fan air baffle
b) Hard drive fan air baffle
Note: The hot-plug drive fan looks similar to the fan used in the Compaq ProLiant 6400R, but operates differently. The
Compaq ProLiant 6400R fan is not compatible with Compaq ProLiant ML530 servers.
continued
