1-6 Compaq ProLiant ML530 Servers Maintenance and Service Guide
Table 1-2
System Components Spare Parts List
continued
Item Description Spare Part Number
Controllers
22 Smart Array 5300 Controller* 171383-001
23 32-MB memory module with battery backup* 171385-001
Cable Kits
24 SCSI cable kit* 159318-001
a) Internal SCSI cable
b) External SCSI cable
25 Miscellaneous power cable kit* 159319-001
26 Miscellaneous signal cable kit* 159320-001
27 Real-time clock battery (4.5-V, 600-mA alkaline battery)* 160274-001
Miscellaneous
28 Maintenance and service guide* 159306-001
29 Country kit, tower* 159307-001
30 Country kit, rack* 159308-001
Hardware
31 Chassis, tower* 159315-001
32 Cover kit, tower* 161660-001
a) Access panel
b) Tower cover
c) Front bezel door
33 Locking casters* 296227-001
34 Tower-to-rack conversion kit* 159317-001
35 Enhanced keyboard* 386209-001
*Not shown
