Removal and Replacement Procedures 2-3
Symbols on Equipment
Any surface or area of the equipment marked with these symbols indicates the
presence of electric shock hazards. The enclosed area contains no
operator-serviceable parts.
WARNING: To reduce the risk of injury from electric shock hazards, do not open
this enclosure.
Any RJ-45 receptacle marked with these symbols indicates a Network Interface
Connection.
WARNING: To reduce the risk of electric shock, fire, or damage to the
equipment, do not plug telephone or telecommunications connectors into this
receptacle.
Any surface or area of the equipment marked with these symbols indicates the
presence of a hot surface or hot component. If this surface is contacted, the
potential for injury exists.
WARNING: To reduce the risk of injury from a hot component, allow the surface
to cool before touching it.
CLASS 1 LASER PRODUCT
This label or equivalent is located on the surface of your CD-ROM drive. This
label indicates that the product is classified as a CLASS 1 LASER PRODUCT.
Power supplies or systems marked with these symbols indicate the equipment is
supplied by multiple sources of power.
WARNING: To reduce the risk of injury from electric shock, remove all power
cords to completely disconnect power from the system.
weight in 93–137 lb
weight in 42–62 kg
Any product or assembly marked with these symbols indicates that the
component exceeds the recommended weight for one individual to handle safely.
WARNING: To reduce the risk of personal injury or damage to the equipment,
observe local occupational health and safety requirements and guidelines for
manual material handling.
