2-32 Compaq ProLiant ML530 Servers Maintenance and Service Guide
System Board Tray
WARNING: To reduce the risk of personal injury or damage to the equipment, do not use the
system board tray handle to lift or move Compaq ProLiant ML530 servers.
IMPORTANT: The system board tray is replaced as one unit. The system board does not have to be
removed from the tray.
To remove the system board tray:
1. Perform the preparation procedures. See “Powering Down the Server” earlier in this
chapter.
2. Remove the access panel. See “Access Panel” earlier in this chapter.
3. Remove the CPU fan air baffle. See “CPU Fan Air Baffle” earlier in this chapter.
